Exocet MM40 B3 V1.rkt Trapezoid Trapezoid Fin Set| Manufacturer: | | | Part Number: | | | Style: | Trapezoid Fin Set | | Material: | Cardboard |
Download as PDF | Root Chord: | 23.0000 inches (584.2000 mm) | | Tip Chord: | 21.0000 inches (533.4000 mm) | | Sweep Distance: | 0.9843 inches (25.0012 mm) | | SemiSpan: | 0.2500 inches (6.3500 mm) | | Point 1: | (0.0000 mm, 0.0000 mm) | | Point 2: | (6.3500 mm, 25.0012 mm) | | Point 3: | (6.3500 mm, 558.4012 mm) | | Point 4: | (0.0000 mm, 584.2000 mm) | | Width: | 0.2500 inches (6.3500 mm) | | Height: | 23.0000 inches (584.2000 mm) |
