Rocketarium AIM-120 AMRAAM Freef Freeform Fin Set| Manufacturer: | Custom | | Part Number: | | | Style: | Freeform Fin Set | | Material: | Balsa |
Download as PDF | Point 1: | (0.0000 mm, 76.2000 mm) | | Point 2: | (50.8000 mm, 76.2000 mm) | | Point 3: | (50.8000 mm, 57.1500 mm) | | Point 4: | (15.7480 mm, 0.0000 mm) | | Point 5: | (0.0000 mm, 0.0000 mm) | | Width: | 3.0000 inches (76.2000 mm) | | Height: | 3.0000 inches (76.2000 mm) |
