Rocketry Parts Database >> Fins >>

Raptor Freeform Fin Set Freeform Fin Set

Manufacturer:Custom
Part Number:
Style:Freeform Fin Set
Material:Balsa

Download as PDF

Point 1:(0.0000 mm, 25.4468 mm)
Point 2:(76.3022 mm, 25.4957 mm)
Point 3:(76.3022 mm, -15.2266 mm)
Point 4:(61.4131 mm, -14.3010 mm)
Point 5:(61.4131 mm, 0.0141 mm)
Point 6:(0.0000 mm, 0.0000 mm)
Width:3.0040 inches (76.3022 mm)
Height:1.6032 inches (40.7224 mm)
