Estes Estes - Vagabond Rocksim Design File

Contributed by Daniel Kirk

• Manufacturer: Estes
• Recovery: Parachute
• Skill Level: 2
• Style: Sport

Download estes_vagabond.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Vagabond (003217)
Diameter: 1.6400 inches
Length: 35.2500 inches
Style: Sport

CG: 19.9615 inches from front
CP: 29.9998 inches from front
Margin: 6.12 Overstable

Parts Breakdown

• estes_vagabond.rkt Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 18.00 in]
• Estes Polyethylene LDPE Parachute (18.00 in)
• Custom Mass Object
• Estes JT-60A Ring
• Estes ESTES 2328 Launch Lug
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 8.00 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.50 in]
• Semroc EH-38 Engine Hook E Mass Object
• Estes E Eng. Hook Sleeve Ring
• Apogee EB-50 Ring
• Estes 30119 Ring
• Estes 30125 Ring
• estes_vagabond.rkt Freeform Fin Set Freeform Fin Set
• Estes ESTES 2328 Launch Lug

Related Kits:

• Estes - Vagabond (003217)
