Corporal - 18mm Rocksim Design File

Contributed by Joe Policy

• Manufacturer: Aerospace Specialty Products
• Recovery: Parachute
• Skill Level: 1
• Style: Scale

Designer: Aerospace Specialty Products (ASP)

Download asp_corporal18.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Aerospace Specialty Products - Corporal {Kit} (KCOR-18)
Diameter: 0.9760 inches
Length: 19.0000 inches
Style: Scale

CG: 6.2022 inches from front
CP: 14.0564 inches from front
Margin: 8.05 Overstable

Parts Breakdown

• Corporal - 18mm Ogive Nose Cone
• Semroc SE-10 Screw Eye Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.13 in]
• Custom Ring
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 14.50 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.76 in]
• Estes 30162-2 Ring
• Estes ESTES 2321 Launch Lug
• Estes ESTES 2321 Launch Lug
• Corporal - 18mm Freeform Fin Set Freeform Fin Set
• Corporal - 18mm Freeform Fin Set Freeform Fin Set
• Corporal - 18mm Trapezoid Fin Se Trapezoid Fin Set
• Custom Mass Object
• Custom Mass Object
• FlisKits CRF-20-50 Ring
• FlisKits CRF-20-50 Ring
• Custom Mylar Parachute (12.00 in)
