oop_estes_eac_viper13mm.rkt Rocksim Design File

Contributed by Alan Kaiser

• Manufacturer: Estes
• Motor Size: 13 mm
• Power: Low-Power
• Recovery: Parachute
• Style: Sport

Download oop_estes_eac_viper13mm.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - E.A.C. Viper {Kit} (0820) [1972-1986]
Style: Sport

CG: 7.9638 inches from front
CP: 11.6219 inches from front
Margin: 3.75 Overstable

Parts Breakdown

• Estes Avenger OOP Ogive Nose Cone
• Semroc SE-10 Screw Eye Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 9.50 in]
• Estes Polyethylene LDPE Parachute (12.00 in)
• LOC Precision SC-250 1/4 In Elastic shock cord Mass Object
• oop_estes_eac_viper13mm.rkt Free Freeform Fin Set
• oop_estes_eac_viper13mm.rkt Trap Trapezoid Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.00 in]
• Custom Ring
• Custom Ring
• Estes Engine hook Standard size Mass Object
• Estes ESTES 2321 Launch Lug
• Estes ESTES 2321 Launch Lug
