Goblin Rocksim Design File

Contributed by Charles Keller

• Designer: Wayne Kellner
• Family: Estes : Goblin
• Manufacturer: Estes

Comments: Estes recommends that this rocket NEVER be flown with the CG located less than 3-5/8" from the rear of the body tube.

Designer: Estes R&D Staff (data entered by Charles Keller based on Kit # K-55 instructions)

Download oop_estes_goblin.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Goblin {Kit} (1255) [1970-1982]

CG: 8.7426 inches from front
CP: 12.1195 inches from front
Margin: 2.55 Overstable

Parts Breakdown

• Bell X-1 Haack Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 9.00 in]
• Goblin Freeform Fin Set Freeform Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.75 in]
• Apogee EB-50 Ring
• Estes Engine hook Standard size Mass Object
• DIY Eye Hook #4 Mass Object
• Custom Mass Object
• Custom Mylar Streamer (0.0010 in)
• Estes ESTES 2321 Launch Lug
• Estes ESTES 2321 Launch Lug
• Custom Ring
• Custom Ring
