DynaStar Stonebreaker Rocksim Design File

Contributed by Dynastar

• Manufacturer: DynaStar
• Motor Size: 24 mm
• Power: Mid-Power
• Recovery: Parachute
• Skill Level: 2
• Style: Military

Comments: Data Entered by Tim Van Milligan

Designer: Shrox

Download dynastar_stonebreaker_v5.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: DynaStar - Stonebreaker {Kit} (05028) [?-]
Diameter: 2.2170 inches
Length: 28.5000 inches
Style: Military

CG: 14.9319 inches from front
CP: 21.7229 inches from front
Margin: 3.06 Overstable

Parts Breakdown

• DynaStar Stonebreaker Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 18.00 in]
• DynaStar Stonebreaker Trapezoid Trapezoid Fin Set
• DynaStar Stonebreaker Trapezoid Trapezoid Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.75 in]
• Estes Engine hook Standard size Mass Object
• Apogee 13031 Ring
• Custom Ring
• Custom Ring
• Custom Polyethylene LDPE Parachute (32.00 in)
• Custom Mass Object
• Public Missiles LL-0.25 Launch Lug
