G3 Rocksim Design File

Contributed by Jacob Pfund

• Manufacturer: Performance Rocketry

Designer: Blitz

Download performance_g3.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Performance Rocketry - G3 {Kit}

CG: 40.9353 inches from front
CP: 67.1987 inches from front
Margin: 8.40 Overstable

Parts Breakdown

• Arreaux 3 Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 22.00 in]
• Public Missiles Ltd. Ring
• Giant Leap Rocketry Rip stop nylon Parachute (60.00 in)
• Custom Ring
• Custom Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 44.50 in]
• G3 Freeform Fin Set Freeform Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 12.00 in]
• Custom Ring
• Custom Ring
• Custom Ring
• Custom Ring
• Giant Leap Rocketry Rip stop nylon Parachute (24.00 in)
