Quest X-15 Rocksim Design File

Contributed by Ron Watkins

• Manufacturer: Quest
• Recovery: Parachute
• Scale: Aircraft : X-15
• Skill Level: 2
• Style: Scale

Download quest_x-15.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Quest - X-15 {Kit} (2014)
Diameter: 1.3800 inches
Style: Scale

CG: 8.0346 inches from front
CP: 10.3935 inches from front
Margin: 1.71

Parts Breakdown

• Quest X-15 Elliptical Nose Cone
• FlisKits Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.00 in]
• SubAssembly
• RocketChutes.com Rip stop nylon Parachute (12.00 in)
• FlisKits SC-2-18 Shock Cord 18in Mass Object
• FlisKits LL-1-1 Launch Lug
• Quest X-15 Freeform Fin Set Freeform Fin Set
• Quest X-15 Freeform Fin Set Freeform Fin Set
• Quest X-15 Freeform Fin Set Freeform Fin Set
• Quest X-15 Freeform Fin Set Freeform Fin Set
• Quest X-15 Freeform Fin Set Freeform Fin Set
• Quest X-15 Trapezoid Fin Set Trapezoid Fin Set
• FlisKits CRF-20-55 Ring
• FlisKits CRF-20-55 Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.75 in]
• BalsaMachining.com EB18-P Ring
• FlisKits Mass Object
