AIM-54 Phoenix Rocksim Design File

Contributed by Jonathan Elder

• Manufacturer: Estes

Comments: A small version of a $2,000,000 Air-to-Air missile with a range of 127 miles.

Designer: Design by Estes - Data Entered by Tim Van Milligan

Download oop_estes_aim_54_phoenix.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Phoenix {Kit} (1380) [1982-1998]

CG: 14.4098 inches from front
CP: 21.9966 inches from front
Margin: 2.92 Overstable

Parts Breakdown

• AIM-54 Phoenix Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 7.50 in]
• Estes JT-5C Estes Ring
• Estes Polyethylene LDPE Parachute (18.00 in)
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 14.00 in]
• AIM-54 Phoenix Trapezoid Fin Set Trapezoid Fin Set
• AIM-54 Phoenix Freeform Fin Set Freeform Fin Set
• Estes ESTES 2328 Launch Lug
• Estes ESTES 2328 Launch Lug
• Custom Ring
• Custom Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 7.75 in]
• Eng. Hook Retainer Tube BT-50 Sl Ring
• Estes Engine hook Standard size Mass Object
