Redstar Rocksim Design File

• Manufacturer: Red River Rocketry
• Recovery: Parachute
• Skill Level: 2
• Style: Futuristic
• Style: Futuristic/Exotic

Download rrr_redstar.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Red River Rocketry - Redstar {Kit} (K-016)
Diameter: 1.3250 inches
Length: 24.5000 inches
Style: Futuristic/Exotic

CG: 14.6787 inches from front
CP: 20.0669 inches from front
Margin: 4.08 Overstable

Parts Breakdown

• Redstar Ogive Nose Cone
• Semroc SE-12 Screw Eye-Large Mass Object
• LOC Precision SC-250 1/4 In Elastic shock cord Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 5.25 in]
• BalsaMachining.com CR5055-F Ring
• BalsaMachining.com CR52H55-F Ring
• Estes ESTES 2328 Launch Lug
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 12.00 in]
• BalsaMachining.com CR2050-F Ring
• Aerospace Speciality Products CR Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.00 in]
• RingTail
• Semroc EH-28 Engine Hook Standard Mass Object
• Redstar Trapezoid Fin Set Trapezoid Fin Set
• BalsaMachining.com CR5055-F Ring
• BalsaMachining.com CR5055-F Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.42 in]
