Designs >> Rocksim Library >>	All Rocksim Designs (1603 of 3219)Tag - Manufacturer:Excelsior Rocketry

HONEST GOON Rocksim Design File

• Manufacturer: Excelsior Rocketry

Comments: Weights and CG as built by GA Dean

Designer: Estes (Based on popular Estes "Big Bertha)

Download excelsior_honest_goon.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Excelsior Rocketry - Honest Goon {Plan}

CG: 6.3000 inches from front
CP: 10.9793 inches from front
Margin: 2.11

Parts Breakdown

• HONEST GOON Parabolic Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.87 in]
• Estes ESTES 2321 Launch Lug
• Balsa Machining Service Conical Transition
• Semroc SE-12 Screw Eye-Large Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 7.50 in]
• Estes 30125 Ring
• Estes 30125 Ring
• Estes Polyethylene LDPE Parachute (12.00 in)
• Custom Mass Object
• HONEST GOON Freeform Fin Set Freeform Fin Set
• Estes ESTES 2321 Launch Lug
• Custom Mass Object
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.75 in]
• Estes 30162-2 Ring
• Estes Engine hook Standard size Mass Object
