Estes - Hi-Flier XL Rocksim Design File

• Family: Estes : Hi-Flier
• Manufacturer: Estes
• Motor Size: 24 mm
• Power: Low-Power
• Recovery: Parachute
• Skill Level: 2
• Style: Sport

Comments: Rocksim file created by Doug Szczepanski Sr. OEM motor recommendations: C11-3, *D12-5, D-12-7, E12-6, E12-8 OEM max altitude estimate: 1,325' on E12-6 *best overall selection

Designer: Estes

Download Hi-Flier XL - Estes 3226_ds.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Hi-Flier XL {Kit} (3226) [2012-]
Diameter: 1.6400 inches
Length: 31.0000 inches
Style: Sport

•

Parts Breakdown

• Estes Parabolic Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.25 in]
• Estes Polyethylene LDPE Parachute (18.00 in)
• LOC Precision SC-250 1/4 In Elastic shock cord Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.25 in]
• Custom Paper Ring (1.5000 - 1.5900 in)
• Estes ESTES 2328 Launch Lug
• Custom Balsa Freeform Fin Set
• SubAssembly
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.50 in]
• Estes 30162-2 Ring
• Estes Engine hook 24 mm (E length) Mass Object
• Custom Paper Ring (0.9799 - 1.5900 in)
• Custom Paper Ring (0.9799 - 1.5900 in)
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 1.00 in]
