Designs >> Rocksim Library >>	All Rocksim Designs (1183 of 3219)Tag - Manufacturer:Estes

Astrocam Rocksim Design File

Contributed by Kathy Miller

• Manufacturer: Estes

Comments: drawn bt A.hobbs

Designer: Estes

Download oop_estes_astrocam.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Astrocam 110 {Kit} (1327) [2004-2008]

CG: 8.9749 inches from front
CP: 14.3884 inches from front
Margin: 4.02 Overstable

Parts Breakdown

• Astrocam Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.00 in]
• Astrocam Freeform Fin Set Freeform Fin Set
• Estes ESTES 2321 Launch Lug
• Estes ESTES 2321 Launch Lug
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.37 in]
• Custom Mass Object
• Estes Estes Ring
• Custom Mylar Parachute (12.25 in)
• Custom Ring
• Custom Ring
• Astrocam Freeform Fin Set Freeform Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 1.00 in]
