Hellfire AGM-114A Rocksim Design File

Contributed by Evan Schmidt

• Manufacturer: The Launch Pad
• Motor Size: 24 mm
• Power: Low-Power
• Power: Mid-Power
• Recovery: Parachute
• Scale: AGM-114 Hellfire
• Skill Level: 3
• Style: Scale

Comments: Mid Power Hellicopter-Launched Anti-Armor Missile

Designer: U.S. Army/Launch Pad Inc.

Download tlp_hellfireagm_114a.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: The Launch Pad - Hellfire AGM-114A {Kit} (K054)
Diameter: 2.6000 inches
Style: Scale

Parts Breakdown

• Hellfire AGM-114A Elliptical Nose Cone
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 19.06 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 1.00 in]
• The Launch Pad 10675-XCR Ring
• The Launch Pad 10675-XCR Ring
• Custom Launch Lug
• Custom Mylar Parachute (23.10 in)
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.25 in]
• The Launch Pad 10675-ECR Ring
• The Launch Pad 10675-ECR Ring
• The Launch Pad 10675-ECR Ring
• Hellfire AGM-114A Freeform Fin S Freeform Fin Set
• Hellfire AGM-114A Freeform Fin S Freeform Fin Set
