Estes - Magician Rocksim Design File

• Manufacturer: Estes
• Motor Size: 24 mm
• Power: Low-Power
• Power: Mid-Power
• Recovery: Parachute
• Skill Level: 3
• Style: Payload
• Style: Sport

Comments: Another Simulation By Bruce S. Levison.

Download Estes Magician EST 2440.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Magician {Kit} (1943, 2440) [2010-]
Diameter: 1.3250 inches
Length: 33.5000 inches
Style: Payload

Parts Breakdown

• Estes Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.00 in]
• Estes Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 18.00 in]
• Estes Cardboard Launch Lug (0.2200 in)
• Estes 038369 1/4" x 30" Flat Rubber Shock Cord Mass Object
• Estes Polyethylene LDPE Parachute (18.00 in)
• Estes Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 6.00 in]
• Estes Paper Ring (1.2200 - 1.2700 in)
• Estes Cardboard Launch Lug (0.2200 in)
• Estes Balsa Freeform Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.00 in]
• Estes 035022 E size Mass Object
• Estes Cardboard Ring (0.7400 - 0.9300 in)
• Estes Cardboard Ring (0.9800 - 1.2600 in)
• Estes Cardboard Ring (0.9800 - 1.2600 in)
